Color / Monochrome Mini Speed Dome 368X Power Zoom

15-CD523W
Add to inquiry box
Production information
Color / Monochrome Mini Speed Dome 368X Power Zoom


  • 1/4” SONY Super HAD CCD
    (Samsung SCM-2230)
  • 3.5~80.9 mm with 23x optical and 16X zoom to give a total of 368X zoom
  • High performance picture control with advanced DSP
  • 0.03 Lux ( ICR on )
  • IR Cut Removable
  • Mask motion detect / H & V reverse
  • Pan range 360°, Speed 0.5~240°/s
  • Tilt range 90°, Speed 0.5~120°/s
  • 128 Preset positions
  • 1 Auto cruising track and 1 Scan
  • NTSC or PAL system
  • AC100V~250V / DC12V universal included
  • AC24V optional(15-AC24-1A extra purchase)
MODEL 15-CD523W
Sync System Internal / External (AC-Lock) +/- 1Hz
CCD 1/4” SONY Super HAD CCD
Effective Pixels NTSC: 768(H) x 494(V) / PAL: 752(H) x 582(V)
S/N Ratio More than 52dB
Horizontal Resolution 560 TV Line(Color),680 TV Line(B/W)
Lens F1.6 / f= 3.5(W)~80.9(T) mm
Digital zoom 23X Optical Zoom and 16X Digital Zoom (The Total Zoom Ratio 368X)
Removable IR Cut Yes
White Balance ATW / AWC / Manual
IRIS AUTO / Manual
AGC Auto Gain Control (+24dB Max.)
White Balance Range 3200°K~9600°K
BLC Function Super BLC, 48 Zone BLC
Illumination 0.03 Lux
Video Signal Output 1.0 Vp-p / 75Ω
Picture Effect Posi./ Nega/ Freeze/ Cross line/ Mask Motion Detect/ H&V Reverse
Electronic Shutter 1/60(1/50) ~ 1/120,000 sec. / Manual: 8 Steup
Control Function RS-485
Protocol Pelco D/P, COP-2
Pan Pan Range 360°, Speed 0.5~240 °/s
Tilt Tilt Range 90°, Speed 0.5~120 °/s
Preset 128 Preset Positions (Max)
Auto Cruise 1 Auto Cruising Tracks (Max)
Operation Temperature -10°C~50°C
Operation Humidity Within 85% RH
Power Source DC12V +/- 1.0V , 3.6 W (Max) , 0.3A
